Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm

The engineering capability for dust collector system is very strong ,I am very satisfied with the quality and service of Hangzhou Grace.

—— David Owens

I have ordered the Nomex filter bag from Hangzhou Grace for 5 years ,I am always enjoy the good quality filter bag supplied by them.

—— Barbara Haselton

ECOGRACE provide with our company for effective solutions about filter media for the dust emission control for our coal fird boiler baghouse system !

—— Steve Brain

I'm Online Chat Now

Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm

China Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm supplier
Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm supplier Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm supplier

Large Image :  Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS / ISO 9001
Model Number: 150x3000mm

Payment & Shipping Terms:

Minimum Order Quantity: 100ps
Price: negotiated
Packaging Details: Poly bag or Paper cartons
Delivery Time: 10 days
Payment Terms: T/T , L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 20000pcs/month
Contact Now
Detailed Product Description
Filter Cloth: Nomex Filter Cloth Application: Smelting Furnace Fumes
Working Temprature: 190 Degree C Applied: Dust Collection System
Working Life: Over 36 Months

Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm





Quick Details:



1. Material: Nomex filter felt
2. Size: 160x6000mm
3. Woring temperature: 190 degree C - 204 degree C
4. Finishing: Water and oil repellent
5. Application: Asphalt mixing , steel mill blast furnace , cement plant





Description of dust collector Filter bags:



Nomex filter bags is the special filter media can be applied in Asphalt mixing plant , it is the most cost effective filter bags for high temperture smoke.



Nomex  filter bag  offerring one of the best total economies in a filtration system because of higher air to cloth ratios, higher temperature resistant function ,and long wearing life  and cheaper price .





Properties of dust collector Filter bags :



1)  Performs at high temperatures



It is  used in  continuously  operating temperatures up to 218°C , and Nomex filter bags  can handle higher temperature surges.



 2) Resists flexing and abrasion



Flex  and abrasion resistance function  of Nomex filter bag at ambient temperature is good .



3)  Good retardant function of moisture



Nomex filter bag  performs well at high operating temperatures with normal amounts of moisture.



The wear life projections in the below graphs were developed using 6-10% H20.



4) Dimensional Stability



Nomex filter bag , Aramid filter bag  is one of the most dimensionally stable dust  filter bags  available. Fibers of Nomex properly manufactured and finished , should neither stretch nor shrink over 2% when operated at temperatures up to 218°C  (425°F ).



5)  High temperatures resistant



The most effective use of Nomex filter bag , aramid filter bag is in high efficiency filtering systems  where effluent temperatures are above 250°F or in  systems with surges over 250°F.  In hot gas filtration systems.



Will work very well in higher air to cloth ratio.



Applications:



Nomex filter bag for higher temperature dust filtration , widely applied in Asphalt mixing plant , cement Kiln  dust filtration , steel melting furnace fumes  filtration and so on .



It offers one of the best total economies in a filtration system because of higher air to cloth ratios, higher temperature capability, and a long working  life.



Specifications:



Article Name

Nomex filtration felt

Ingredients

Fiber

100% Nomex

Scrim

100% Nomex

Weight

g/m2

500

Thickness

mm

2.1

Density

g/m³

0.24

Permeability

L/dm2.min

150

Tensile breaking

strength(N/5cm)

Warp

≥800

Weft

≥1000

Elongation @200N/5cm

Warp

<5

Weft

<5

Maximum shrink

of 90 mins

Temperature(°C)

250

%

≤1

Service Temperature(°C)

Continuous

190

Instant

240

Finishing

Singeing, calendaring.





Speciality



1. High Temperature resistant

2. Resists flexing and abrasion

3. Effect of moisture

4. Good chemical resistance

5. Dimensional Stability

6. Flame resistance





Meta Aramid Dust Collector Filter Bags Nomex / Aramid Filter 160x6000mm
