Small Cement Pulse Jet Bag Filter Equipment High Temperature Smoke Filters

Large Image : Small Cement Pulse Jet Bag Filter Equipment High Temperature Smoke Filters

Product Details:

Place of Origin:	China
Brand Name:	ECOGRACE
Certification:	SGS

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiated
Packaging Details:	container
Delivery Time:	45 days
Payment Terms:	T/T ,L/C
Supply Ability:	200 sets /month

Contact Now

Detailed Product Description

High Light:

pulse jet fabric filter

reverse pulse jet bag filter

Small Cement Pulse Jet Bag Filter Equipment High Temperature Smoke Filters

Description:

Asphalt mixing site special design Bag filter equipment,A high collection efficiency, small footprint, stable, reliable performance, easy maintenance of large bag filter equipment. Asphalt Mixing Dust Collector Bag Filter Equipment Baghouse Dust Collector.

Bag Filter Dust Collector Equipment For Industries as Cement / Asphalt mixing / Metal smelting

Quick Details of ECOGRACE Dust Collector :

1. ECOGRACE provide the dust collector from smaller size Filter Unit to bigger size dust collection systems.

Smaller Filter Unit with capacity of gas volume from 5000 M3/H to 30000M3/H.

The bigger dust collection system with capacity from 30000M3/H to 1000000M3/H.

2. ECOGRACE provide the complete service include design,manufacturing, installatin guide, trial running and after sale technical support.

3. ECOGRACE also provide the most effective and cost effective design for easy shipping, and provide the most cost effective design to establish the dust collecting systems for oversea customers.

4. Lower emission to 20mg/M3, the filtration efficiency up to 99.99%.

Applications:

1 iron, steel mill, ferroalloy plant, refractory plant, foundry, power plant of flue gas dedusting system etc.Asphalt Mixing Dust Collector Bag Filter Equipment Baghouse Dust Collector

2 Wastes incinerator, coal fired boilers, fluid fluidized bed boiler flue gas filter etc.

3 Asphalt mixing, building materials, cement ceramic, lime and gypsum and other production sites.

4 Aluminum electrolysis, lead and tin, zinc, copper and other rare metal smelting gas filtering,superfine material recovery, liquid and solid separation.Asphalt Mixing Dust Collector Bag Filter Equipment Baghouse Dust Collector

5. thermal power plant ,cement plant , metallurgy industry, chemical industry, the characteristics of smoke, for the successful development of power plant boiler, cement rotary kiln, steel mills, coke oven blast furnace.Asphalt Mixing Dust Collector Bag Filter Equipment Baghouse Dust Collector

Specifications:

Model		CGQM 32-3	CGQM 2-4	CGQM 32-5	CGQM 32-6	CGQM 64-4	CGQM 64-5	CGQM 64-6	CGQM 64-7	CGQM 64-8
Air volume (m³ /h)		6900	8930	11160	13390	17800	22300	26700	31200	35700
Total filter area (m²)		93	124	155	186	248	310	372	434	496
Chamber(pcs)		3	4	5	6	4	5	6	7	8
Quantity of filter bag(pcs)		32				64
Total quantity of filter bag(pcs)		96	128	160	192	256	320	384	448	512
Pulse valve	Quantity(pcs)	3	4	5	6	4	5	6	7	8
	Specification(inch)	2				2 1/2
Specification of filter bag(Dmm*Lmm)		130*2450
Filter material		Based on flue gas properties
Filtration speed(m/min)		0.8~2.0(Adjustable)
Negative pressure(Pa)		less than 6000
Resistance(Pa)		1470~1770
Inlet dust concentration		less than 200				less than 1000
Blowing pressure(Mpa)		0.5~0.7
Compressed air consumption(Nm3/min)		0.27	0.37	0.46	0.55	1.2	1.5	1.8	2.1	2.4
Air-locking unit		Adjustable
Screw conveyor		No				Adjustable
Area of heat preservation(m2)		28.3	35.8	45.1	56.8	71	96.2	120.2	142.6	176

Competitive Advantage:

1. It has modern design, it uses lower gas inlet structure, the rough high temperature granules directly drop to the dust hopper and effectively protects the filter bag.

2. It uses long filter bags and it has smaller floor area in case of equal processing capacity, therefore it is more convenient for reconstruction of old factories.

3. It uses separate chamber offfline dust clearing with high efficiency and few secondary flour dust attachment, in the meantime, it can effectively reduce the equipment energy consumption, the fatigue level of filter bag and pulse valve is correspondingly reduced and the service life of filter bag and vane is prolonged by several times and equipement operation cost is remarkably reduced.

4. The overhaul and bag replacement can be carried out for separate chambers under the condition that system blower and system run normally.

5. The filter bag inlet used spring tension structure, it is convenient to disassemble & assemble and it has good tightness.

6. The case uses airtightness design and it carries out leak detecting with oil and reduces air leak to the maximum extent.

7. The whole set of equipment is controlled by PLC to realize automatic dust cleaning, dust removal, automatic temperature control and over temperature alarm.
