Automatic Pulse Jet Bag Filter / Dust Remove System With Nomex Filter Bags

China Automatic Pulse Jet Bag Filter / Dust Remove System With Nomex Filter Bags supplier

Large Image :  Automatic Pulse Jet Bag Filter / Dust Remove System With Nomex Filter Bags

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiated
Packaging Details: container
Delivery Time: 45 days
Payment Terms: T/T ,L/C
Contact Now
Detailed Product Description

Automatic Pulse Jet Bag Filter / Dust Remove System With Nomex Filter Bags





BAG HOUSE BAG FILTER:

Model No. :GMC1012

Application: Asphlat Mixing Plant

Dust type: High Temperature Smoke

Air flow :60000m³/h-85000m³/h

Gas Temperature :160 C degree -190 C degree

Filter bag chosen: Nomex Filter Bags

Working life of filter bag:3 years

Running resistance:1500pa



ECOGRACE BAG FILTER WORKED In FOLLOWING ASPHLAT MIXING PLANT WORKING CONDITIONS:

GLB3000



Asphalt Plant  Production capacity: 240t/h (under standard working condition)

Standard working condition: altitude≤1000m, environmental

Temperature: 20°C,

Standard atmospheric pressure, average moisture content of the cool aggregate is 5%

The temperature of hot aggregate: 160°C

Cycling time: 45S Finished products is the medium-grained state



 Standard weight measuring (static state )

Accuracy of metering

Sandstone : ±0.5%

Powder lot :±0.25%

Asphalt :±0.2%



Dust—collecting efficiency >99.99%

Dust discharging <=50mg /M2

 Temperature  stability

The temperature stability of the hot aggregate: ±5°C

The temperature stability of the finished product: ±3°C





Advantage of ECOGRACE BAG FILTER  :



         1. ECOGRACE BAG FILTER, it has taken the temperature gas to lower temperature gas inlet structure, the rough high temperature granules directly drop to the dust hopper and effectively protects the filter bag.

         2. The longer filters dust collector take smaller area which will increase the processing capacity, therefore it is more convenient for reconstruction of old factories.

         3. ECOGRACE take separate chamber off line dust cleaning in bag filter  design and it is with high efficiency and few secondary flour dust attachment, meanwhile it can effectively save the energy consumption. Such design effectively protect the filter bags and pulse valve and save the operation and  maintenance cost for the dust collector system.

         4. The filter bags will be replaced without stop the filtration system.

         5. ECOGRACE Dust Collector with ECOGRACE made filters which is made with snap band with good sealing, easy for assemble and replacement and good tightness.

         6. ECOGRACE take Air leaking detecting with oil and to keep all the system  air leaking  <0.5%.

         7. Our Bag Filter Dust Collector is controlled by PLC to realize automatic dust cleaning, dust removal, automatic temperature control and over temperature alarm.
