|Place of Origin:||China|
|Certification:||SGS / ISO 9001|
|Minimum Order Quantity:||1 set|
|Delivery Time:||45 days|
|Payment Terms:||T/T ,L/C|
|Supply Ability:||200 sets /month|
|Type Of Dust Collector:||Baghouse Dust Collector Long Filter Low Pressure||Filtration Area:||1680 M2|
|Filtration Speed:||1.0 M/min||Operation Temperature:||Less Than 190 Degree C|
|Air Flow:||100000.00 M3/H||Filters:||Nomex Filter / Polyester Filter|
|High Light:||pulse jet fabric filter, reverse pulse jet bag filter|
5 Micron Air Filtration Pulse Jet Bag Filters Industrial For Water Treatment
ECOGRACE are the leading manufacturer specialized in designing and manufacturing baghouse dust
collectors inChina with the over 10 years experience of manufacturing high quality bag filter dust collector.
We provide solution for standard working conditions bag filter dust collector, and special solutions
for high pressure, high temperature and high corrosive working conditions.
Application of Dust Collector :
ECOGRACE Bag Filter Dust Collector is widely applied in Asphalt mixing site, cement plant, gypsum plant,
steel plant, coal fired boiler,etc. ECOGRACE always providing the cost-effective filtration solutions for
all of our clients.
About the series of Low Pressure Long Bag Pulse Dust Collector
1. ECOGRACE BAG FILTER DUST COLLECTOR,it has taken the temperature gas to lower
temperaturegas inlet structure,the rough high temperature granules directly drop to the dust hopper and effectively protects the filter bag.
2. The longer filters dust collector take smaller area which will increase the processing capacity,
therefore it ismore convenient for reconstruction of old factories.
3. ECOGRACE take separate chamber off line dust cleaning in bag filter dust collector design and it is with high efficiency and few secondary flour dust attachment,meanwhile it can effectively save the energy consumption.Such design effectively protect the filter bags and pulse valve and save the operation and maintenance cost for the dust collector system.
4. The filter bags will be replaced without stop the filtration system.
5. ECOGRACE Dust Collector with ECOGRACE made filters which is made with snap band with good sealing,easy for assemble and replacement and good tightness.
6. ECOGRACE take Air leaking detecting with oil and to keep all the system air leaking<0.5%.
7. Our Bag Filter Dust Collector is controlled by PLC to realize automatic dust cleaning,dust removal,automatic temperature control and over temperature alarm.
|Dust Collector Model No.||DMC1680|
|Filter speed||1.0 M/min|
|Filter area||1680 M2|
|Operation Temperature||lese than 190 degree C|
