1.0 ~ 1.2 m / min Dust Collector Systems with 1500~1700 Pa Dust Collector resistance

China 1.0 ~ 1.2 m / min Dust Collector Systems with 1500~1700 Pa Dust Collector resistance supplier

Large Image :  1.0 ~ 1.2 m / min Dust Collector Systems with 1500~1700 Pa Dust Collector resistance

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS
Model Number: SGS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiated
Packaging Details: container
Delivery Time: 45 days
Payment Terms: T/T ,L/C
Supply Ability: 200 sets /month
Contact Now
Detailed Product Description

Cement Plant Dust Collection Equipment , Baghouse Dust Collector




ECOGRACE are the leading manufacturer specialized in designing and manufacturing baghouse dust collectors in China with the over 10 years experience of manufacturing high quality bag filter dust collector. We provide solution for standard working conditions bag filter dust collector, and special solutions for high pressure, high temperature and high corrosive working conditions.

ECOGRACE Bag Filter Dust Collector is widely applied in Asphalt mixing site, cement plant, gypsum plant, steel plant, coal fired boiler,  etc.

ECOGRACE always providing the cost-effective filtration solutions for all of our clients.

About the series of  Low Pressure Long Bag Pulse Dust Collector

Description:
Cement kiln applied Bag filter ,long bag pulse jet ,high  efficiency,
A high collection efficiency, small footprint, stable, reliable performance, easy maintenance of large bag filter equipment.

It combines the sub-room cleaning and the characteristics of pulse cleaning, to overcome the general sub-room cleaning and the general lack of intensity pulse cleaning dust and then attached to the shortcomings of the bag and longer air force into full play the role of cleaning. It is s a high collection efficiency, stable, reliable performance, easy maintenance of large bag filter  dust removal equipment. DMC series of large pulse length bag filter is our  advanced technologies based on thermal power plant ,cement plant , metallurgy industry, chemical industry, the characteristics of smoke, for the successful development of power plant boiler, cement rotary kiln, steel mills, coke oven blast furnace, and other special high long bag filter.


Applications:

1. iron, steel mill, ferroalloy plant, refractory plant, foundry, power plant of flue gas dedusting system etc.

2 Wastes incinerator, coal fired boilers, fluid fluidized bed boiler flue gas filter etc.

3 Asphalt mixing, building materials, cement ceramic, lime and gypsum and other production sites.

4 Aluminum electrolysis, lead and tin, zinc, copper and other rare metal smelting gas filtering,superfine material recovery, liquid and solid separation.
5.thermal power plant ,cement plant , metallurgy industry, chemical industry, the characteristics of smoke, for the successful development of power plant boiler, cement rotary kiln, steel mills, coke oven blast furnace





             Model

GPC96-5

GPC96-6

GPC96-7

GPC96-8

GPC96-9

Input air (m3/h)

A

bigger than 100g/N m3

26000

33000

40000

46000

52200

B

≤100g/N m3

33400

40100

46800

53300

60100

Filtering wind speed (m/min)

1.0~1.2



Gross filter area (square meters)

480

576

672

768

864

Net filter area (square emters)

384

480

576

672

768

Collector House (pcs)

5

6

7

8

9

Number of Filter bags (pcs)

480

576

672

768

864

Diameter of filter bags

130mm

Dust Collector resistance (Pa)

1500~1700

Outlet dust density (mg/N m3 )

less than 50

Dust collector bear pressure (Pa)

9000

Clear ash, Air Compress

Pressure (Pa)

(4~6)×105

Consumption     ( N m3/min )

0.9(1.8)

0.9(1.8)

0.9(1.8)

0.9(1.8)

1.2(2.5)

Regidity fans appending machine

Feed400×400 Rotate speed 22.5rpm Decelerate Elector power 2.2KW

Screw conveyor or airslide conveyor

Specification

LS400×4.4m

LS400×5.62m

LS400×6.84m

LS400×8.06m

LS400×9.28m

Gear motor

TY-31.5-2.2

2.2KW

TY112-35.5-4

4KW

Heat preservation covers (square meters)

120

130

140

150

160

Weight of Equipment (kg)

(Insulation course not included)

11800

13500

15200

18000

19600
