Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag

China Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag supplier
Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag supplier Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag supplier Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag supplier

Large Image :  Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS
Model Number: 130x5000

Payment & Shipping Terms:

Minimum Order Quantity: 100ps
Price: negotiated
Packaging Details: Poly bag or Paper cartons
Delivery Time: 25 days
Payment Terms: T/T ,L/C
Supply Ability: 20000pcs/month
Contact Now
Detailed Product Description
Weight: 500gsm Thickness: 2.4mm
Diameter: 120-180mm Length: 2000-8000mm
Constant Working Temperature: 210degree Warranty: 12months

Pulse Jet Nomex Needle Felt Filter Fabric , 1 Micron Dust Collector Bag Filter


Nomex Filter medias

Application of Nomex Needle Felt Filter Fabric:
Nomex Filter medias are mainly used in cement industry, asphalt industry, metallurgical industry and tobacco industry for flue gas purification.

Performance of Nomex Needle Felt Filter Fabric:
Continuous operating temperature is up to 200°C, instant service temperature is up to 240°C
 Fire retardant performance is excellent
Corrosion resistance and alkali resistance is good
Excellent thermal stability, excellent abrasion resistance and flexural resistance   Hydrolysis resistance is poor, frequent SOx and vapor in flue gas or dew point will  greatly reduce its service life

Specification of of Nomex Needle Felt Filter Fabric


Article Name

Nomex needled felt

Ingredients

Fiber

100% Nomex



Scrim

100% Nomex

Weight

g/m2

500

Thickness

mm

2.1

Density

g/m³

0.24

Permeability

L/dm2.min

150

Tensile breaking
strength(N/5cm)

Warp

≥800



Weft

≥1000

Elongation @200N/5cm

Warp

<5



Weft

<5

Maximum shrink
of 90 mins

Temperature(°C)

250



%

≤1

Service Temperature(°C)

Continuous

200



Instant

240

Finishing

Singeing, calendaring.Water and oil repellent treatment



Description:
All types of dust filter bags for dust collector system ,Various coatings and finishing on the fabrics of the dust filter bags  can be applied to either side of the  to enhance cleaning and efficiencies of dust collector system , as well as prolonging service life. Ground wire, anti-collapse rings, and other options can easily be incorporated into bag construction.  can custom fabricate various types of attachments to work with your specific shaker mechanism, whether  a loop, eyelet, grommet, or other device.
All types of dust filter bags for dust collector system Dust filter bags  are carefully fabricated and sized to ensure ease of installation and change-out. Generally, dust collector filter bags are designed to be mounted and gasketed firmly into place with a snap band, corded cuff, or clamp to ensure dust type seal.
Filter bags, dust collector bag ,dust filter bag , dust bags, filter socks, - they all mean the same thing: An industrial grade fabric filter made from heavy duty material, all textile based, used in dust collecting systems, in either process filtration or pollution control.
The main type of dust filter bags including Nomex filter bag ,PPS filter bags ,P84 filter bag ,Polyimide filter bag ,PTFE filter bags ,Acrylic filter bags ,Polyester filter bags,dust filter bag ,bag filters,dust collector bags.

Good Quality Industrial Polyester Dust Collector Filter Bag
1 - Good quality polyester filter material made with advanced machinery
2 - Accordingly adjusted technical process
3 - Strict raw material control and products quality control
4 - Competitive price

Tailor service ,just let us know your request ,we will give exact recommendation .
Steel plant furnace smoke filter Nomex bag filter D 160XL 4500MM


  • What kind of product that showed on our website do you need? PTFE fiber, PTFE Sewing thread, dust filter cloth and dust filter bag?
  • If you want buy filter cloth or felt and filter bag, tell me if you need membrane lamination.
  • The size of dust filter and collect bag.
  • Is it a revise air or pluse jet?
  • Flat Dimension.
  • Specs on Material.
  • Is it a Top or Bottom Load Collector?
  • Your  working conditions  such as temperature resistance, chemical resistance.Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag
  • Pulse Jet Fabric Filter Bags , Dust Collector 1 Micron Filter Bag
