PTFE Fiber Polyester Needle Felt Filter Bags With Water Repellent

China PTFE Fiber Polyester Needle Felt Filter Bags With Water Repellent supplier
PTFE Fiber Polyester Needle Felt Filter Bags With Water Repellent supplier PTFE Fiber Polyester Needle Felt Filter Bags With Water Repellent supplier

Large Image :  PTFE Fiber Polyester Needle Felt Filter Bags With Water Repellent

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS
Model Number: 160X8000

Payment & Shipping Terms:

Minimum Order Quantity: 100ps
Price: negotiated
Packaging Details: Polybag in cartons
Delivery Time: 25 days
Payment Terms: T/T ,L/C
Supply Ability: 20000pcs/month
Contact Now
Detailed Product Description
Weight: 500gsm Thickness: 1.9mm
Diameter: 120-180mm Length: 2000-8000mm
Constant Working Temperature: 90 Degree Warranty: 12 Months



PTFE Fiber Polyester Needle Felt Filter Bags With Water Repellent





Description of Polyester Needle Felt Filter Bags :



Polyester filter bags  are carefully fabricated and sized to ensure ease of installation and change-out. Generally, dust collector filter bags are designed to be mounted and firmly into place with a snap band, corded cuff, or clamp to ensure dust type seal.

Various coatings and finishes can be applied to either side of the dust collector Polyester filter bag to enhance cleaning and efficiencies, as well as prolonging service life. Ground wire, anti-collapse rings, and other options can easily be incorporated into bag construction.  can custom fabricate various types of attachments to work with your specific shaker mechanism, whether  a loop, eyelet, grommet, or other device.

Filter bags, dust collector bag ,dust filter bag , dust bags, filter socks, - they all mean the same thing: An industrial grade fabric filter made from heavy duty material, all textile based, used in dust collecting systems, in either process filtration or pollution control.

The main type of dust filter bags including Nomex filter bag ,PPS filter bags ,P84 filter bag ,Polyimide filter bag ,PTFE filter bags ,Acrylic filter bags ,Polyester filter bags,dust filter bag ,bag filters,dust collector bags.





Applications of Polyester Needle Felt Filter Bags :



Coal industry,  cement industry, asphalt mixing industry, carbon black industry, chemical industry, power plants, smelting industry, etc.It can be continuously used in smoke and gas filtration in  asphalt factory, cement kiln , waste incinerator, fluid boiler, and coal-burning boiler, etc.





Specifications of Polyester Needle Felt Filter Bags :



Media

Weight(g/m2)

Material
Weaving/Scrim

Thickness
(mm)

Temperature
continuous/Max

Surface treatment

Polyester filter felt

600g/m2

PE/PE

1.9

135 /150

singed on one side

Ployster,oil and water ,
dirt repellent finish filter

550g/m2

PE/PE

1.7

135 /150

singed on one side
oil  and  water  repellent  finish
cleanability  supporting  finish

Polyster+antistatic

550g/m2

PE/PE

1.7

135 /150

singed on one side , antistatic

PPS high-temperature resistant

550g/m2

PPS/PPS

1.7

190 /200

singed on one side

PTFE high-temperature
resistant corrosion prevention

700g/m2

PTFE/PTFE

1.2

250 /280

singed on one side , corrosion prevention

Polyster+PTFE membrance

550g/m2

PE/PE

1.7

135 /150

singed on one side,PTFE membrance

P84 high-temperature resistant

550g/m2

P84/P84

2.8

240 /260

singed on one side  corrosion prevention

 FMS high-temperature resistant

550g/m2

FMS/FMS

2.2

200 /200

singed on one side





Competitive Advantage:



Polyester filter bags take  Quality raw materials
High-end production facilities
Good sewing job
Strict QC
Experienced technical & production

Good Quality Industrial Polyester Dust Collector Filter Bag,Polyester filter bag

1 - Good quality polyester filter material made with advanced machinery

2 - Accordingly adjusted technical process

3 - Strict raw material control and products quality control

4 - Competitive price




Tailor service ,just let us know your request ,we will give exact recommendation .

  • What kind of product that showed on our website do you need? PTFE fiber, PTFE Sewing thread, PTFE membrane or dust filter cloth and dust filter bag?
  • If you want buy filter cloth or felt and filter bag, tell me if you need membrane lamination.
  • The size of dust filter and collect bag.
  • Is it a revise air or pluse jet?
  • Flat Dimension.
  • Specs on Material.
  • Is it a Top or Bottom Load Collector?
  • Your  working conditions  such as temperature resistance, chemical resistance.
