ECOGRACE Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation

China ECOGRACE  Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation supplier
ECOGRACE  Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation supplier ECOGRACE  Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation supplier ECOGRACE  Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation supplier

Large Image :  ECOGRACE Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS / ISO 9001 2008
Model Number: PP3288

Payment & Shipping Terms:

Minimum Order Quantity: 30 PCS
Price: negotiated
Packaging Details: Poly Bags
Delivery Time: 1-4 weeks
Payment Terms: T/T, L/C, D/P, D/A, Western Union, MoneyGram
Supply Ability: 30000 pcs/ month
Contact Now
Detailed Product Description
Filter Cloth: Polypropylene PP Filter Cloth Micron Rating: 30 - 50 Micron
Shape Of Filter Press: Square Application: Liquid Filter For Mining , Chemical , Metallurgy
Filter Type: Press Filter Cloth

ECOGRACE Fabric Filter Press Cloth PP / PE sludge Dewatering Micron Water Filtation

We have filter cloth applied for the Belt Press Filter and Membrane Filter Press.



Quick Detail:

a. Filter Cloth : PE Filter Cloth , PP  Filter Cloth , PA Filter Cloth ,

b. Working temperature: normal working temperature 88 degree C , 110 Degree C peak working temperature.

c. Weight standard: 250g / sqm - 900 g / sqm . Make to order is also accepted.  Send us your sample filter cloth , we will give our confirmation in 24 hours .



Filter press fabric / filter press cloth / filter press plate cloth

Woven filter press cloth used for sludge dewatering



Model No. And Specifications:

Model material

Weight

(g/m2)

Thickness

(mm)

Air permeability

(l/m2.s)

Breaking strength

(N/5x20CM)

Elongation

(%)

Density

(pcs/10cm)

weave
warp weft warp weft Peak. Cont.
PP 750A PP 450 0.79 26 3104 2663 38 30 222 154 PLAIN
PP 750B PP 517 1.27 30 2608 2050 35 28 256 151 TWILL
PP 750BB PP 740 1.40 8 10115 3030 35 30 582 110 SATIN
PP 750AB PP 650 1.30 20 7800 5200 26 20 450 170 TWILL
PP 4212 PP 380 1.07 123 2972 1942 24 37 236 123 TWILL
PE 8222 PE 700 1.5 8 720 450         TWILL



ECOGRACE Liquid Filter Cloth : PET, PP , PA6 , PA 66 Filter Cloth , Mono-filament Filter Cloth , Multi-filament Filter Cloth .

Type of Filter Cloth Bag :Filter press plate , centrifuge Filter , Leaf filter , fluid bed dryer, Rotary / Horizontal DISC filter .

Liquid Filter Bag Application :

Chemical Industry :

Catalyst, cobalt carbonate, zinc oxide, zirconium carbonate, activated carbon, cobalt carbonate, borate, dyes and intermediates , iron oxide , nickle, salt , aluminum oxide , titanium dioxide, additives , glycerol , pesticides , white carbon black , zinc , calcium carbonate , etc.



Mining Industry :

Red mud , tailing gold , potash fertilizer , vanadium ore , the end of coal, clean coal, coal washing , clay , Kaolin clay, etc.



Metallurgical Industry :

Gold, molybdenum, leads , vanadium , nickel , zinc , copper, tungsten , carbide slag , etc.



Food processing :

Fruit juice, sugar, starch , sweetener, beer , etc.

Environmental protection: Sewage treatment, sludge dewatering , flue gas desulphurization, salt mud , fly ash, etc.



APPLICATION AND FILTER CLOTH CHOOSING :

P0802Y zinc oxide
T0803t Potash fertilizer
P120D/P050D/P080D/P020MD Double layer monofilament filter cloth
P050D, P030MD, P020MD FGD, Gypsum
N9029 Iron ore concentrate
N199 Iron ore concentrate
P1010 Iron ore concentrae
P020MD Iron ore concentrate
9501-32 Fly ash, coal ash
9501-35 Fly ash
9501-34 Zinc oxide
P1010sdy Zinc sulfate
PT9502b-41DY Gold mining , vanadium mine
9502-40 Borax, vanadium pentoxide
PT9502b-31 Gold
P750AB Copper
P120/P190 Phosphate
MP11343Y Copper
9502-402DY Iron sulfide
9503-32 Catalyst
P190 Beer filtration
P199s/P11636: Sugar filtration
N120B Palm oil filtration, other oil, use anti-static filter cloth
P1010-37DY Titanium Dioxide
3233SY White carbon black
3233SY/108C/P801IIy Kaolin
T3112BY/3233SYY Pigment, dyestuff



Benefits

High dimensional stability,

Good abrasion performance,

Wide range of filter rate

Efficient fabric cleaning
