Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth

China Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth supplier
Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth supplier Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth supplier Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth supplier Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth supplier

Large Image :  Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth

Product Details:

Place of Origin: China
Brand Name: ECOGRACE
Certification: SGS / ISO 9001 2008
Model Number: PP3927

Payment & Shipping Terms:

Minimum Order Quantity: 20PCS
Price: negotiated
Packaging Details: Poly Bags
Delivery Time: 1-4 weeks
Payment Terms: T/T, L/C, D/P, D/A, Western Union, MoneyGram
Supply Ability: 30000 pcs/ month
Contact Now
Detailed Product Description
Filter Cloth: Monofilament Filter Cloth For Liquid Filtration Micron Rating: 30 Micron -100 Micron
Weaving Of Filter Cloth: Plain / Twill Application: Coal Washing , Coal Washery, Slurry Dewatering
Filter Type: Press Filter Cloth , Disc Filter , Leaf Filter Filament Of Filter Cloth: Multiple Filament / Monofilament
Sample: Free Sample

Waste water treatment Slurry Dewatering Filter Press Cloth For Filter Press

Solid Liquid Separation Filter Press Cloth Belt Press Cloth



Filter Press Cloth , Belt Filter Cloth ,

a. Filter Cloth : Polyester Filter Cloth , Polypropylene Filter Cloth , PA Filter Cloth , Nylon Filter Fabric

b. Working temperature: normal working temperature 88 degree C , 110 Degree C peak working temperature.

c. Weight standard: 250g / sqm - 900 g / sqm . Make to order is also accepted.



Filter press fabric / filter press cloth / filter press plate cloth

Vertical DISC Filter Machine Filter Cloth ,

Leaf Filter machine filter cloth



Woven filter press cloth for sludge dewatering , recessed filter press , membrane filter press



Model No. And Specifications:

Model material

Weight

(g/m2)

Thickness

(mm)

Air permeability

(l/m2.s)

Breaking strength

(N/5x20CM)

Elongation

(%)

Density

(pcs/10cm)

weave
warp weft warp weft Peak. Cont.
PP 750A PP 450 0.79 26 3104 2663 38 30 222 154 PLAIN
PP 750B PP 517 1.27 30 2608 2050 35 28 256 151 TWILL
PP 750BB PP 740 1.40 8 10115 3030 35 30 582 110 SATIN
PP 750AB PP 650 1.30 20 7800 5200 26 20 450 170 TWILL
PP 4212 PP 380 1.07 123 2972 1942 24 37 236 123 TWILL
PE 8222 PE 700 1.5 8 720 450         TWILL



ECOGRACE Liquid Filter Cloth : PET, PP , PA6 , PA 66 Filter Cloth , Mono-filament Filter Cloth , Multi-filament Filter Cloth .

Type of Filter Cloth Bag :Filter press plate , centrifuge Filter , Leaf filter , fluid bed dryer, Rotary / Horizontal DISC filter .

Liquid Filter Bag Application :

Chemical Industry :

Catalyst, cobalt carbonate, zinc oxide, zirconium carbonate, activated carbon, cobalt carbonate, borate, dyes and intermediates , iron oxide , nickle, salt , aluminum oxide , titanium dioxide, additives , glycerol , pesticides , white carbon black , zinc , calcium carbonate , etc.



Mining Industry :

Red mud , tailing gold , potash fertilizer , vanadium ore , the end of coal, clean coal, coal washing , clay , Kaolin clay, etc.



Metallurgical Industry :

Alumina / Aluminum oxide Plant Filtration , Gold, molybdenum, leads , vanadium , nickel , zinc , copper, tungsten , carbide slag , etc.



Food processing :

Fruit juice, sugar, starch , sweetener, beer , etc.

Environmental protection: Sewage treatment, sludge dewatering , flue gas desulphurization, salt mud , fly ash, etc.



APPLICATION AND FILTER CLOTH CHOOSING :

P0802Y zinc oxide
T0803t Potash fertilizer
P120D/P050D/P080D/P020MD Double layer monofilament filter cloth
P050D, P030MD, P020MD FGD, Gypsum
N9029 Iron ore concentrate , ALUMINA , ALUMINUM OXIDE
N199 Iron ore concentrate
P1010 Iron ore concentrae
P020MD Iron ore concentrate
9501-32 Fly ash, coal ash
9501-35 Fly ash
9501-34 Zinc oxide
P1010sdy Zinc sulfate
PT9502b-41DY Gold mining , vanadium mine
9502-40 Borax, vanadium pentoxide
PT9502b-31 Gold
P750AB Copper
P120/P190 Phosphate
MP11343Y Copper
9502-402DY Iron sulfide
9503-32 Catalyst
P190 Beer filtration
P199s/P11636: Sugar filtration
N120B Palm oil filtration, other oil, use anti-static filter cloth
P1010-37DY Titanium Dioxide
3233SY White carbon black
3233SY/108C/P801IIy Kaolin
T3112BY/3233SYY Pigment, dyestuff



Benefits

High dimensional stability,

Good abrasion performance,

Wide range of filter rate

Efficient fabric cleaning

Smooth Surface

Easy Cake Releasing .

Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter ClothSolid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth

Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter ClothSolid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth

Solid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter ClothSolid Liquid Separation Filter Press Cloth Belt Press Cloth PP Filter Cloth
